Pipe Cutting CNC Fiber Laser Machine For Various Steel SS

This is professional steel tube cutting machine which is suitable for all kinds of steel tube like round pipe, square tube, oval tube, rectangle tube, H steel, angle steel and channel steel. It can satisfy various tube cutting process such as tube cutting-off, pipe hole cutting, profiling or any other shapes cuttings.
Availability:

PDF Export

  • U-T6/9/12

  • UNIQUE CNC

Applications Of The 5 Axis CNC Pipe Cutter

This is professional steel tube cutting machine which is suitable for all kinds of steel tube like round pipe, square tube, oval tube, rectangle tube, H steel, angle steel and channel steel.  It can satisfy various tube cutting process such as tube cutting-off, pipe hole cutting, profiling or any other shapes cuttings.


Demo Video Of The 5 Axis Fiber Laser Cutting Machine for tubes cutting


Advantages Of Unique CNC Fiber Laser Cutting Machine For Steel SS Tubes Cutting

1). The machine adopts Raycus/Max fiber laser generator, Swiss Raytools auto focus laser heads, Japan servo motors and reducers, Taiwan guide rails and blocks, and other famous brand and top quality components, guarantee the longest lifespan and stable performance.

2). The cutting diameter up to 600mm, cutting length up to 12m.

3). Support Solidworks,Autocad,etc.

4). Equips with wireless handle.


Parameters Of The CNC Pipe Cutter

1
Model
U-T6/9/12
2
Cutting materials
steel, SS round tube,square tube,oval tube,rectangle tube,angle steel, channel steel,H steel
3
Cutting length
6m/9m/12m (others are customized)
4
Diameter options
320mm/420mm/500mm/600mm
5
Fiber laser Generator
Raycus / IPG /MAX
6
Transmission system
Gear + rails
7
X.Y axis max moving speed
60m/min
8
Cutting accuracy
0.02mm
9

Cutting thickness

0.2-20mm


CNC Fiber Pipe Cutting Effect

pipe cutting effect

tube cutting fiber machine
