U-R1330-A
UNIQUE CNC
1. Furniture Industries
Cabinet doors,closets,doors,windows,tables,chairs,customized furniture and so on.
2. Decoration Industries
Waveboards, slatwall panel, wall hanging,advertisement board and so on.
1. Auto feeding
2. Auto vertical drilling (5+4 drills)
3. Auto nesting
4. Auto tools changing
5. Auto locating
6. Auto lubricate
7. Auto switching to different sizes panels when auto loading
Main features of Unique Automatic CNC Panel Furniture Production Line:
1. Heavy duty structure, machine body and gantry are tempered,reduce the excess hardness, increase the toughness of steel, whole machine will not deform forever.
2. Anti-rust treatment of the structures, after at least two layers painting, the looks are smooth,beautiful and durable.
3. All the parts on the machine are famous brand and toppest quality,like original Schneider electrical components, Airtec air components, original Delta limits, Germany materials made cables, etc.
4. 2M grinding high precision and high speed helical gear racks,guarantee machine`s high cutting speed and precision.
5. Well organized cables,wires all with labels, so in the future if machine break,we can find out the problem and fix it immediately.
6. Advanced lubricate system can avoid the liquid leaking or backflowregorge.
7. Professional testing equipments makes the machine higher precision than industry standard, the X,Y and Z levelness and verticality are all adjust by laser plumb instrument, the errors are within 0.03mm.
8. Automatic double dust collecting system. The front dust collecting system is for the cutting spindle while the back dust collecting for the wood panels pushing system. After double dust collecting, no any chips or exhaust escape, give your factory totally clean environment.
9. Dual cylinders locating system for different size panels. We can set different panel sizes in the controller, the locating system will be active according to different panel sizes.
Specifications of Unique CNC Auto Feeding CNC Production Line:
Specification | Details |
Model | U-R1330-A auto loading and unloading cnc nesting machine |
Traveling size | 1300x3000x300mm (Other sizes are optional) |
Spindle | 9KW air cooled, 0-24000rpm,HSD brand, ISO 30 holder, ER32 collet |
Transmit | Taiwan made guide rails, X and Y axis are 30mm width, Z axis is 25mm width X and Y axis are all transmit by Taiwan made 2M gear rack, Z axis is transmit by Taiwan made TBI or PMI brand ball screws |
Tool magazine | Circle type auto tool changer drove by servo motor, 16 tools |
Worktable | Vacuum table |
Dust collector | 5.5KW, two bags |
Control system | Syntec 60WE controller |
Lubricate system | Electrical auto lubricate |
Locating pop-up pins | Three sets at side, two sets at front |
Tool sensor | High sensitive tool sensor |
Voltage | 220V/380V/3 Phase/50Hz |
Item | Parameter |
Travel size | 1350x3050x300mm |
Travelling speed | 80-120m/min |
Working speed | 35-45m/min |
Machine error | <0.01mm |
Running Environment | Temperature: -10~55 degrees, Relative Humidity: 30%~75% |
Auto Loading table | Size: 1200x2400mm Structure material: Manganese steel Hydraulic fluid: 46# Voltage: 380V |
Auto unloading table
| Size: 1300x2500x700mm Capacity:50kg/m² Moving speed: 0-25m/min Sensor protector included |
Samples:
