6 Heads Wood 3D Engraving CNC Router For Mass Production

The 6 heads wood CNC Router can process 6 pieces workpieces at a time, improve the productivity greatly.

PDF Export

  • U-R2030-6


Advantages of The 6 Heads 3D Engraving CNC Router:

1. The 6 heads CNC Router is able to process 6 same workpieces at a time,improve the productivity greatly.

2. Distances between the heads are adjustable manually.

3. Each head has its own inverter, so once one inverter breaks, only one head is affected, other heads still can work normally.

4. There are enhanced steel strips on the structure,at the position where install the rails, this can give most support to the rails,make the machine more stable and durable.

5. Combined vacuum table and T-slot table, can hold the materials by suction or clamps.

6. 1500W servo driving, Z axis motors have brake function to avoid the Z axis falling down when power off suddenly.

7. Taiwan made guide rails,bearings and ballscrews, more smooth, less noisy and longer life.

Functions of The Six Spindles 3D CNC Engraving Machine:

1. 3D carving on various wood, PVC,acrylic and so on.

2. Cutting on wood,plywood,MDF, PVC, chipboard and so on.

3. Milling on wood.

Parameters of the 6 Spindles Wood CNC Router:

Model No.U-R2030-6 six heads wood engraving CNC Router
Working size2000x3000x300mm
Heads quantity6
Spindle power6KW air cooling (Others are optional), ER32 collet
Driving system1500W Leadshine servo driving
Speed reducerShimpo reducers
Guide rails25mm linear square guide rails and blocks
Transmission X and Y axis are transmit by rack and pinion

Z axis is transmit by ballscrews

No-load speedX and Y axis: 45m/min,    Z axis: 15m/min
TableCombined vacuum table and T-slot table
ControllerTaiwan LNC (DSP, Ncstudio, Mach3, Syntec are optional)
CommandG code
Compatible softwaresArtcam,Vcarve,Aspire,Rhino and other CAD/CAM softwares
Machine voltage 380V/220V
Machine dimension3600x2600x1900mm
